The REVARO T-REX966 is a powerful 6-ton class front-end loader engineered for demanding material handling and earthmoving applications. With a rated load of 6,000 kg and a large 3.5 m³ bucket capacity, it delivers excellent productivity across construction sites, quarries, and bulk material operations.
Powered by a robust 178 kW WD10G240E203 engine and paired with a Beilian transmission (F2/R1), the T-REX966 offers strong breakout force (188 kN) and impressive drawbar pull (220 kN) for heavy-duty performance. Its 20,100 kg operating weight ensures stability, while the open-center hydraulic system provides smooth, efficient lifting with a 5.7-second boom raise time.
Built with a heavy-duty drivetrain, planetary final drive reduction, and durable 26.5-25 L-3 tires, the T-REX966 is designed to handle tough terrain with confidence and reliability.
Specifications
- Brand: Revaro
- Model: T-REX966
- Type: Front-End Loader
- Max. Drawbar Force: 220kN
- Breakout Force: 188kN
- Dump Clearance: 3050mm
- Transmission Type: Beilian
- Forward I Speed: 11.6km/h
- Forward II Speed: 38.5km/h
- Final Drive Reduction Type: Planetary type, single stage
- Boom Raise Time: 5.7MPa
- System Pressure Setting (Hydraulic): 20MPa
- Parking Brake: Drum/Shoe
- Steering System Type: Load sensingply
- Steering Pump Type: Piston pump
- System Pressure Setting (Steering): 18
- Tire Size: 26.5-25
- Tire Type: Bias
- Tire Layer: 32
- Tire Pattern: L-3
- Rated Load: 6,000kg
- Operating Weight with Standard Bucket: 20,100kg
- Bucket Capacity: 3.5m³
- Wheel Base: 3,400mm
- Overall Dimension: 8,704 x 3,092 x 3,458m
- B-Pin Height (for Std. Linkage): 4,196mm
- Transmission Gears: F2/R1
- Reverse I Speed: 15.5km/h
- Main Drive Type: Spiral bevel gear, single stage
- Rear Oscillation: ±11°
- Engine Model: WD10G240E203
- Rated Power: 178kW
- Rated Speed: 2000r/min
- Displacement: 9.7L
- Implement System Type: Open center flow sharing
- Hydraulic Cycle Time: 9.8s
- Service Brake: Dry & caliper, air to oil control
- Steering Angle (L/R): 38±1°
Available new from Bethlehem Vurkhyser Velddienste, with delivery, finance options and backup from our Bethlehem workshop. Contact us for pricing and availability.
